15 Settings PIOX S70x
UMPIOX_S7V4-6-3EN, 2018-10-10 137
15.2.2 Medium Pressure
The dependence of the properties of a medium on the pressure can be taken into account.
15.2.3 Measuring Point Number
15.2.4 Transducer Distance
15.2.5 Steam in the Supply Line
15.2.6 Temperature Correction
During the next scroll through the program branch Parameter, the outer pipe diameter
that corresponds to the entered pipe circumference will be displayed.
example: 180 mm : = 57.3 mm
Note! The pipe circumference is only edited temporarily. When the transmitter switches back to the display
of the pipe circumference (internal recalculation), slight rounding errors may occur.
Example: entered pipe circumference: 100 mm
displayed outer pipe diameter: 31.8 mm
When the transmitter switches back to the display of the pipe circumference, 99.9 mm will be dis-
played.
If on has been selected, the medium pressure will be requested in the program branch Pa-
rameter.
If off has been selected, 1 bar will be used for all calculations.
Note! For documentation purposes, it is useful to enter the medium pressure, even if the transmitter con-
tains no pressure-dependent characteristic curves.
Select (1234) if the measuring point is to be identified only by numbers, point and dash.
Select (↑↓←
→) if the measuring point is to be designated with ASCII characters.
recommended setting: user
• user will be selected if the measuring point is always the same.
• auto can be selected if the measuring point changes often.
In the program branch Measuring, the recommended transducer distance will be dis-
played in parentheses, followed by the entered transducer distance if the recommended
and the entered transducer distance are not identical.
During transducer positioning in the program branch Measuring
• only the entered transducer distance will be displayed if Transd. Distance = user
has been selected and the recommended and the entered transducer distances are
identical
• only the recommended transducer distance will be displayed if Transd. Distance =
auto has been selected.
Select on if the medium in the supply line can be vaporous during the heat flow measure-
ment (see section 17.6). In this case, the supply pressure will have to be entered in the pro-
gram branch Parameter.
Select on to enable the input of a temperature correction for each temperature input (see
section 18.2.5).
Meas.Point No.:
(1234) >(↑↓← →)<
Transd. Distance
auto >USER<
Transd. Distance?
(50.8) 50.0 mm
