SYSTEM settings\Libraries\Extended Library
selection of the displays for the activation of the extended library
activation of the extended library x
SYSTEM settings\Dialogs/Menus
selection of the displays for the activation/deactivation or setting of the menu
items in the other program branches
activation of the menu item for the input of the pipe circumference in the pro-
gram branch Parameter
x
activation of the menu item for the input of the medium pressure in the program
branch Parameter
x
selection of the input mode for the measuring point number in the program
branch Measuring:
(1234): digits, point, hyphen
(↑↓←
→): ASCII editor
x
setting for the display for the input of the transducer distance in the program
branch Measuring:
• user: only the entered transducer distance will be displayed if the recom-
mended and the entered transducer distances are identical
• auto: only the recommended transducer distance will be displayed
recommended setting: user
x
activation of the menu item for the input of the supply pressure in the program
branch Parameter for a heat flow measurement in a medium that can be a liq-
uid or a gas in the supply line
x
activation of the menu item for the input of a correction value (offset) for each
temperature input in the program branch Measuring
x
selection of the error value delay
• damping: The damping factor will be used.
• edit: The menu item for the input of the error value delay in the program
branch Output Options will be activated.
x
activation of the display of the alarm state during the measurement x
selection of the unit of measurement for the length x
selection of the unit of measurement for the temperature x
selection if the absolute pressure p
a
or the relative pressure p
g
is to be used x
INIT-
resistant
Libraries ↕
Extended Library
Extended Library
off >ON<
SYSTEM settings↕
Dialogs/Menus
Pipe Circumfer.
off >ON<
Fluid pressure
off >ON<
Meas.Point No.:
(1234) >(↑↓← →)<
Transd. Distance
auto >USER<
Steam in inlet
off >ON<
Tx Corr.Offset
off >ON<
Error-val. delay
damping >EDIT<
SHOW RELAIS STAT
off >ON<
Length unit
>[mm]< [inch]
Temperature
>[°C]< [°F]
Pressure absolut
off >ON<
