B Menu Structure PIOX S70x
UMPIOX_S7V4-6-3EN, 2018-10-10 185
selection of the character for column separation x
selection of the serial interface
default: RS232
This display will only be indicated if the transmitter has an RS485 interface.
x
SYSTEM settings\Network
change of the settings of the transmission parameters of the RS485 interface
input of the address of the measuring instrument x
confirmation or change of the transmission parameters x
change of the baud rate, parity or number of stop bits x
SYSTEM settings\Miscellaneous
selection of the display for the setting of the contrast
setting of the contrast of the display
Instrum. Inform.
selection of the displays for information about the transmitter
display of the type, serial number and max. available data logger memory x
display of the type, serial number and firmware version with the date (dd - day,
mm - month, yy - year)
x
Print Meas.Val.
selection of the displays for the transmission of stored measured values to a PC
start of the transmission of measured values
This display will only be indicated if the data logger contains measured values
and the transmitter is connected to a PC via a serial cable.
display of the data transmission progress
INIT-
resistant
SER:col-separat.
’;’ >’TAB’<
Send Offline via
RS232 >RS485<
SYSTEM settings
Network
Device address:
0 ADR
RS485 protocol
default >SETUP<
>BAUD< parity st
1200 EVEN 1
SYSTEM settings
Miscellaneous
SETUP DISPLAY
CONTRAST
Special Funct.
Instrum. Inform.
S70X -XXXXXXXX
Free: 18327
S70X -XXXXXXXX
V x.xx dd.mm.yy
Special Funct.
Print Meas.Val.
Send Header 01
................

................
