7 Connection PIOX S70x
UMPIOX_S7V4-6-3EN, 2018-10-10 65
Tab. 7.11: Terminal assignment (extension cable, KL2)
terminal connection
TV white or marked cable (core)
TVS white or marked cable (internal shield)
TRS brown cable (internal shield)
TR brown cable (core)
Fig. 7.23: Connection of the extension cable and the transducer cable
to the junction box JBxx (example with JB01)
extension cable
transducer cable
