PIOX S70x 7 Connection
76 UMPIOX_S7V4-6-3EN, 2018-10-10
1
For the display and the setting of the switchable current loop see section 19.1.
binary output (opto-
relay)
S704
S705
Pxa
Pxb
U
ext
26 V
I
c
100 mA
binary output (open
collector) Px+/Pxa
Px-/Pxb
U
ext
= 5...24 V
R
c
[k] = U
ext
/I
c
[mA]
I
c
= 1...4 mA
P1...P4: R
i
= 22
binary output (Reed
relay) Px+/Pxa
Px-/Pxb
U
max
= 48 V
I
max
= 100 mA
P1...P4: R
i
= 22
RS485
S704
S705
A+
B-
120
termination resistor
shield 101
RS485
S709
4A+
4B-
120
termination resistor
shield 43
Tab. 7.19: Circuits of the outputs
output transmitter external circuit remark
internal circuit connection
The number, type and connections of the outputs are customized.
R
ext
is the sum of all ohmic resistances in the circuit (e.g. resistance of the conductors, resistance of the ampere-
meter/voltmeter).
R
c
U
ext
V
+
-
R
i
R
c
U
ext
V
+
-
a
b
R
i
+
-
+
-
