6.3.2.2 Kenwood
ThetunerrequiresbothbanddataandaPTTlinefromKenwoodradios.BanddataisavailableusingtheCAT
protocolviaRS‐232.
PTT
Connectanappropriatecablebetweentheradio'sPTToutputandthePTTInputcorrespondingtothetuner
Port(AorB).Somemodelsmayrequirea
customcabletoaccessradioPTTfromanaccessoryconnector.
PleaseconsultyourmanualforthecorrectPTToutput.Multi‐bandradiosmayhavemorethanone,basedon
thebandyouareoperating.BelowisanexampleusingtheREMOTEconnectoronaTS‐2000.Inthiscase,[pins

2and4]wouldbeconnectedtothetuner'sPTTINonPORTAorPORTB.

BandData(CAT)

RS‐232(CAT)connectionsuseastraight‐throughfemale‐to‐femaleDB9cable.
ConnecteithertheCATInputA orCATInputBconnectoronyourTunerGeniusXL
totheCATconnectoronthe
Kenwoodtra nsceiverusin gafemale‐to‐femaleDB9cable.
