1.2 Locations in the operating instructions
All directions and locations in these instructions are based on the operator's workstation.
Front Rear
Fig. 1: Locations in the documentation
Top
Front Rear
Left side view
Fig. 2: Main views of the ULW transfer trailer (ULW 30 tandem shown)
1.3 Illustrations used
Instructions and system responses
The steps to be taken by operating personnel are presented in the form of a (numbered) list.
These steps must be followed in the correct order. The system response to each operator action is
marked with an arrow. Example:
Operator action step 1
 System response to operator action step 1
1.4 Cross references
Cross references to other points in the operating instructions appear in the text along with the relevant
chapter and subchapter or section.
