3.5 Assemblies and components
Item no.
Title
1
Longitudinal screw conveyor
2
Inclined screw conveyor
3
Discharge tube
4
Hydraulic cylinders
5
Compressed air connections
6
Hydraulic connector
7
Hose holder
8
Supporting mechanism
9
Draw gear
10
Flange coupling
11
Drive shaft attachment
12
Body
13
Axle assembly
14
Parking brake
Item 1 – longitudinal screw conveyor
The longitudinal screw conveyor is located in the
floor. It transports the load in the body to the
inclined screw conveyor.
Fig. 7: Assembly – item 1
Item 2 – Inclined screw conveyor
The inclined screw conveyor transports the load out
of the transfer trailer via the discharge tube.
