Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany
Hydraulic connections
Connect all hydraulic lines to the towing vehicle in pairs (partially double action).
For labelling to identify connection points, see the markings on the couplings.
Slide gate (dosing feeder)
Discharge tube hydraulics
Hydraulic supporting foot
[Colour of dust cap]
Fig. 52: Hydraulic hose markings
- Check all hydraulic lines for damage and leaks on a daily basis.
- Replace all hydraulic hoses completely every 6 years.
Releasing the parking brake
The hand brake lever is located on the right of the traction bar.
Spindle brake version:
To release the parking brake on the trailer, turn the crank anti-clockwise.
- Remove the wheel chocks and stow them.
- Start the towing vehicle engine.
- Retract the supporting mechanism and, if possible, secure it in place.
- Check the service brake and parking brake before starting work.
Road traffic regulations must also be observed when using the brakes (including the
parking brake).
7.1.4 Electrical and electronic control accessories
Separate instructions are provided for the electronic controls.
See section 10.
Fliegl Weighing System (FWS)
Fliegl Tracker
