13. Axles
13.1 Assemblies
13.1.1 Gigant tandem assembly
Fig. 72: Gigant assembly
13.1.2 Gigant Plus tandem assembly
Fig. 73: Gigant Plus tandem
13.1.3 Gigant Plus tridem assembly
Fig. 74: Gigant Plus assembly
13.2 Axle maintenance work
For information on the required maintenance work for the relevant axles, please contact the
manufacturer of the installed axles. The necessary data is provided on the type plate of the installed
axles.
Links to maintenance manuals:
BPW: https://www.bpw.de/service/downloads.html
ADR: http://www.adraxles.de/download
FAD: http://www.fadassali.it/eng/manuals_e.aspx
The axle manufacturer can provide you with the latest maintenance manuals.
