Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany
8. Basic equipment (standard, optional)
8.1 Flange couplings
The flange couplings are assigned to different total vehicle weight classes.
The following drawbar eyes are available for the transfer trailer:
DIN drawbar eye 40 (Ø 40 mm)
Drawbar with swivelling eye
(Ø 51 mm)
Pivoting drawbar eye
(50 mm, up to 14 t)
8.2 Supporting mechanism
Depending on the ASW version, the following types
of supporting mechanism are available.
Versions
1. Hydraulic supporting foot
2. Hitch supporting foot, rigid (optional)*
* Export only
1 2
Fig. 56: Supporting mechanism
8.3 Viewing window
The bulkheads feature viewing windows as standard
so that the contents of the body can be seen from
outside. A ladder is fitted to the rear for this purpose.
