Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany
9.5 Universal terminal with colour touchscreen
The universal terminal can be used to
operate the ISOBUS control systems.
The operating instructions are supplied
separately (see section 10).
Fig. 63: Universal terminal
9.6 Farm-Box, data logger
This is used to record and transfer the values of the
Fliegl FWS to the portal. For this purpose, the
Farm-Box uploads a task controller (data logger
function) as soon as the ignition voltage is
activated.
On the Farm-Box itself, the middle LED behind the
flap next to the CF card must light up green when
the ignition is on and a CF card with the correct
software and corresponding licence file must be
inserted.
Nothing must be altered on the CF card!
Changes are made only by the manufacturer.
The LED on the top of the Farm-Box indicates the
GPS reception and the connection to the server.
The operating instructions are supplied separately
(see section 10).
9.7 Other optional accessories
- Roller cover with platform
- Dosing hose attachment, hose 150 mm
- Discharge chute, hydraulically adjustable
- Drive shaft
