Description of the machine
Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany
3. Description of the machine
This section gives a complete overview of the layout and function of the machine.
If possible, read it at the machine. That is the best way for you to familiarise yourself with the machine.
3.1 Applications
The machine is used to transport and spread goods as described in section 2.1 "Designated use".
3.2 Design variants
Standard versions:
ULW 20 Single-axle Gross vehicle weight 12,500 kg
ULW 25 VARIO Single-axle Gross vehicle weight 12,500 kg
ULW 25 VARIO Tandem Gross vehicle weight 20,000 kg
ULW 30 VARIO Tandem Gross vehicle weight 20,000 kg
ULW 40 VARIO Tridem Gross vehicle weight 29,000 kg
ULW 45 VARIO Tridem Gross vehicle weight 29,000 kg
3.3 Functional description
The transfer trailer is a centre-axle trailer and is used to transfer the load to a different transport vehicle.
Loading the machine
The trailer is loaded from above:
using an external working machine
(wheel, telescopic, front loader, combine harvester etc.)
Unloading the machine
At the unloading point:
Following completed transport:
1. The drive shaft is activated
2. Operation of the longitudinal and inclined screw conveyors begins
3. The load is transported from the longitudinal to the inclined screw conveyor
4. The load is emptied by the inclined screw conveyor via the discharge tube
