Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany
6.7 ISOBUS control
6.7.1 ISOBUS weighing system (optional)
If the ULW is equipped with the ISOBUS weighing system, the weights in the body can be measured
immediately and logged for additional processes.
To use the weighing system, the towing vehicle must be prepared for ISOBUS
applications. This preparation includes the following:
- ISOBUS socket incl. wiring harness
Control terminal or signal socket with sensor distributor
- Sensors (if required)
If your towing vehicle is not prepared for ISOBUS, contact your dealer to discuss
retrofit options.
Detailed information on system operation is provided in the separate operating
instructions for the weighing system.
Control terminal
The ISOBUS weighing system is operated via
the tractor terminal or a separate control
terminal.
Fig. 41: Control terminal (different model shown)
Weighing sensor
The weighing sensor has an accuracy of
+/- 0.1% of the payload or +/- 10 kg.
Prompt weighing of the load in the field, even
on inclines.
Ensure that the sensor cable is securely
fastened and undamaged.
