INTRODUCTION
The Learjet 45 fuel system consists of the fuel storage, quantity indicating, transfer, vent
system and single-point pressure refueling system.
The fuel system is covered in this chapter from the storage areas to the high-pressure engine
fuel pumps, at which point fuel system operation becomes a function of the powerplant.
The fuel system provides for fuel storage, fuel
transfer and low-pressure distribution to the
high pressure engine fuel pumps.
The fuel storage system consists of an integral
wet-wing tank in each wing, a fuselage tank
and a vent system.
Each wing tank contains four transfer jet
pumps (scavenge ejector pumps) which au-
tomatically move fuel to a section of the wing
tank, at the wing root, known as the collector
tank. A fifth transfer jet pump is located within
each wing in each fuselage tank transfer line,
outboard of the collector tanks. The function
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;
