LEARJET 45 PILOT TRAINING MANUAL
2-39
FOR TRAINING PURPOSES ONLY
FlightSafety
international
* NOTE 1: L and R Essential Avionics Buses will also remain powered until L and R AV MSTR switches are
selected OFF, as per AFM procedure.
**NOTE 2: AFM procedure calls for turning DU 2 OFF.
L ESS AV
*
DU 1
RAD ALT 1
L ESS BUS
COMM 1, AUDIO 1, CABIN PA, ADF 1
DME 1, NAV 1, FMS 1, ATC 1
RMU 1 PWR PRI
L DISPLAY CTRL, DU 2
**
IC/SG 1, ADC 1
DAU 1 CH B
AHRS PWR #1 PRI,
AHRS PWR #2 SEC
CVR, L CWP
L SQUAT SW
MAIN HYD PRESS IND
AUX HYD, CTRL
NWS MOTOR, CMPTR
L STALL WARN
SPOILER CTRL
L FLAP POSN
AIL TRIM, PRI PITCH
ELEV DISCONNECT
L WHEEL MSTR
L ESS BUS, VOLTS
L FUEL FLOW
L IGN CH A/B
L ENG CMPTR
L FIRE DET
L TR DEPLOY, ANN, STOW
L OIL PRI/TEMP
L FUEL QTY
L FUEL STBY PUMP PWR/CTRL
L BLEED, LEAK DETECT, PACK
L EMER PRESS
L WSHLD HEAT
CKPT FLOOD, MAP
CKPT INSTRS, L ESS PWR
DOOR LIGHTS
EMER BATT BUS
EMER BUS/VOLTS
DAU1 CH A
DAU2 CH A
STBY ATT GYRO & LIGHTING
STBY ALTIMETER VIBRATOR & LIGHTING
STBY AIRSPEED LIGHTING
GEAR CTRL/IND
PAX OXY (MANUAL DEPLOY)
RMU 1 PWR SEC
INBD BRAKES/ANTI-SKID
CKPT EMER INSTR LTS
R PRESS
EMER LIGHTING (ON GROUND)
R ESS BUS
AUDIO 2
RMU 2 PWR SEC
R CWP, FDR
R DISPLAY CTRL
IC/SG 2, ADC 2
DAU 2 CH B
AHRS PWR #1 SEC
AHRS PWR #2 PRI
R SQUAT SW
OTBD BRAKES/ANTI-SKID
BRAKE ACCUM PRESS
R STALL WARN
SPOILER IND
R FLAP POSN, CTRL
RUD TRIM/FORCE, SEC PITCH
PIT TRIM BIAS
R WHEEL MSTR
R ESS BUS, VOLTS
R FUEL FLOW
R IGN CH A/B
R ENG CMPTR
R FIRE DET
R TR DEPLOY, ANN, STOW
R OIL PRI/TEMP
R FUEL QTY
R STBY PUMP PWR/CTRL
FUEL XFLOW
R BLEED, TEMP CTRL MAN
R WSHLD HEAT
ICE DETECT
STBY PITOT HT
R ESS AV*
DU 3
DU 4
L EMER HOT BUS
L FIRE EXT
L FWSOV
REAR HOT BUS
SPPR/DEFUEL VALVE/FUEL XFLOW
BAGGAGE LIGHTS
TAILCONE UTIL LIGHT
TOILET SVC
EMER LIGHTING
PYLON LIGHTS
R HOT BUS
LEFT CKPT OVRHD LT
ENTRY LIGHTS
RAD CTL HOT BUS RELAY
#1 COMM/NAV
#1 & 2 AUDIO
CLR DEL HEAD
R GEN BUS
R LAND LIGHT
R TAXI LIGHT
BAGGAGE HEAT
NAV LIGHT-FWD
NAV LIGHTS-AFT
SEC PITCH TRIM
R GEN FIELD
L GEN BUS
L LAND LIGHT
L TAXI LIGHT
AUX HYD PUMP PWR
PRI PITCH TRIM
L GEN FIELD
L HOT BUS
NONE
R EMER HOT BUS
R FIRE EXT
R FWSOV
Table 2-4. DC POWER DISTRIBUTION WITH DOUBLE GENERATOR FAILURE
