FlightSafety LEARJET 45 - Page 209

LEARJET 45 PILOT TRAINING MANUAL
8-5
FOR TRAINING PURPOSES ONLY
FlightSafety
international
LH
NACELLE
RH
NACELLE
BLEED AIR
SHUTOFF
VALVE
BLEED AIR
SHUTOFF
VALVE
FUEL
SHUTOFF VALVE
HYDRAULIC
SHUTOFF VALVE
TR ISOLATION
VALVE
FUEL
SHUTOFF VALVE
HYDRAULIC
SHUTOFF VALVE
TR ISOLATION
VALVE
RELIEF VALVE
RELIEF VALVE
TWO-WAY
CHECK
VALVES
PRESSURE GAGE
PRESSURE
GAGE
LH
CONTAINER
RH
CONTAINER
THERMAL
DISCHARGE
INDICATOR
MANUAL
DISCHARGE
INDICATOR
CLOSED
FIRE
PUSH
ARMED ARMED
EXTINGUISHER FIRE
#1 #2
L ENGINE
CLOSED
ARMED ARMED
EXTINGUISHERFIRE
#2 #1
R ENGINE
LEGEND
ENGINE DISCHARGE
MANUAL DISCHARGE
THERMAL DISCHARGE
FIRE
PUSH
L FWSOV CLSD R FWSOV CLSD
Figure 8-4. Engine Fire Extinguishing System
