FlightSafety LEARJET 45 - Page 353

15-10
FOR TRAINING PURPOSES ONLY
LEARJET 45 PILOT TRAINING MANUAL
FlightSafety
international
Figure 15-11. Rudder Trim Tab
PILOT RUDDER ADJUST SWITCH
COPILOT RUDDER ADJUST SWITCH
YAW DAMPER SWITCH
ON FGC
(see Chapter 16)
RUDDER BOOST SWITCH
RUDDER TRIM SWITCH
Figure 15-12. Rudder Controls
TRIM TAB
RUDDER
8" STRIP ADDED
6" STRIP
ADDED
