LEARJET 45 PILOT TRAINING MANUAL
16-62
FOR TRAINING PURPOSES ONLY
FlightSafety
international
N1
ITT
SAT °C
LF
1000
R
1650
FLAPS
20
8.5
PITCH TRIMLBSFUEL
4050
-15
50.0
76
60
980
50.0
80
60
1000
N2
OIL PSI
OIL °C
FF PPH
550
550
75.0
75.0
1400
89.6 89.6
CAS
DISPLAY
AREA
(15 LINES X
18 CHARACTERS)
CAS DIVIDER
LINES
STATIC AIR
TEMPERATURE
DIGITAL READOUT
PITCH TRIM
DIGITAL READOUT
(DIGITS - WHITE/
RED)
FLAPS DIGITAL
READOUT
(DIGITS - WHITE/
AMBER/RED)
SYSTEM PAGE
DIVIDER LINES
FUEL QUANTITY
DIVIDER LINE
MAIN
B-ACUM
CAB ALT
OXY QTY
3000
3000
669
EMER-V
AMPS
TEMP ° C
50 65
30
50
VOLTS
28.5 28.0
28.0
ELECT
HYD/ECS
FLT
SPLR
PIT
AIL
RUD
0
8.5
R 1
L 1
1300
CAS
FUEL
FLT
ECS
HYD
ELEC
SUMRY
Honeywell
Figure 16-36. EICAS Display Format – Display Areas
