Installation of other Shipboard Systems
432-0012-00-12 Version 110 July 2016 19
Installation of other Shipboard Systems
NMEA 0180 Interface
Serial NMEA 0183 interface devices (radar interface for example) can be connected via a Serial
port into the M400 system. The NMEA serial interface is included as pigtail leads on the composite
analog video/serial cable.
Dashed lines represent
connection to power
Analog Video
Customer supplied monitor
NMEA serial inteface
Customer supplied
Ethernet
JCU II
PoE switch
Figure 2-3: Shipboard System
