Warnings and Cautions
432-0012-00-12 Version 110 July 2016 7
Warnings and Cautions
Warning: Do not use the M400 imaging system as the primary navigation system. Use it in
conjunction with other navigation aids and a primary manual navigation system.
Warning: Ensure power is removed before accessing power wires during installation or removal of
system components. DO NOT HOT SWAP components (such as the JCU II). Damage to
equipment or injury to personnel may result.
Warning: The M400 system is not designed to operate in an enclosed environment in the
presence of flammable gases. Failure to follow this warning may result in explosion or fire.
Warning: Use of insufficient wire gauge can result in fire.
Warning: The M400 camera body is a remotely and automatically controlled device. Ensure
camera motion has been disabled before cleaning surfaces that can cause pinch hazards.
Caution: Do not open the M400 camera unit for any reason. Disassembly of the camera (including
removal of the cover) can cause permanent damage and will void the warranty.
Caution: Be careful not to leave fingerprints on the M400 camera optics.
Caution: The M400 requires a power supply of 12 Vdc to 24 Vdc nominal, 5.5 A maximum @ 24
Vdc, 11 A maximum @ 12 Vdc. Absolute voltage range: 12 Vdc to 32 Vdc. Operating the camera
outside of the specified input voltage range or the specified operating temperature range can
cause permanent damage.
Caution: During installation, ensure the cables exiting the camera are not in contact with sharp
edges, do not bend at sharp angles, and are not pinched between the bottom of the camera and
the mounting surface. Do not pull on the cables with excessive force.
Operating temperature range –20 °C to +55 °C (–4 °F to +131 °F) per IEC 60945
Storage temperature range –50 °C to +80 °C (–58 °F to +176 °F)
