General Information
432-0012-00-12 Version 110 July 2016 6
The M400 should be installed by a qualified marine electronics technician;
incorrect installation could void the warranty.
This manual includes information about the following topics:
• Installation overview and planning
• Mounting the camera and installing the Joystick Control
Unit (JCU II)
• Connecting the electronics
• Configuration and Communication using a PC
• Maintaining the camera
• Parts list and other reference information
Additional Installation Components
Contact FLIR Systems, Inc. for more information regarding available accessories including
additional JCU IIs, PoE equipment, video distribution amplifiers, Serial to Ethernet servers, NMEA
Multiplexers, etc.
The Ethernet interface to the M400 camera must support a minimum 100 Mbps communication;
the camera will not communicate at 10 Mbps. This requirement is met if using the supplied PoE+
switch. In order to provide high quality streaming digital video over the Ethernet network, the
network should have a minimum bandwidth of 100 Mbps. Video streams can be adjusted to use a
lower bandwidth, but video quality may be affected.
Additional References
Your M400 camera comes with a complete documentation set available from the FLIR Systems,
Inc. Web site. All documents are in PDF format and can be viewed with Adobe Acrobat Reader:
• M400 Operator’s Manual (FLIR Doc. # 432-0012-00-10) contains information about how to
configure and operate the camera.
• M400 Quick Start Guide (FLIR Doc. # 432-0012-00-11) is a card used as a reference for the
functions executed by the various JCU II buttons.
• M400 ICD (FLIR Doc. # 432-0012-XX-41) is an Interface Description Document providing
detailed installation information.
For safety, and to achieve the highest levels of performance from the M400 system, always follow
the warnings and cautions in this manual when handling and operating the M400 camera system.
Warning notices are used to emphasize conditions that could cause personal injury or death
existing with this equipment, or that may be associated with its use.
Caution notices are used where equipment might be damaged if care is not taken or an operation
might have an unexpected outcome.
Notes call attention to information significant to understanding and operating the equipment.
