Specifications
432-0012-00-12 Version 110 July 2016 43
Specifications
Table 4.1 lists details about physical characteristics, power usage, and environmental features of
your M400 camera.
TABLE 4.1 Specifications
Thermal Imaging
Specifications M400
Sensor Type 640 x 480 VOx Microbolometer
Field of View 18° to 6° HFOV / 1.5° HFOV with e-zoom
Focal Length 35 mm (Wide) to 105 mm (Narrow)
E-Zoom 4X Optical Zoom
Imaging Processing FLIR DDE
Daylight Imaging Specifications
Detector Type Long range color daylight and low light viewing
Resolution High Definition up to 1080/30p
Minimum Illumination >0.5 lux at 50 IRE / .05 Lux in ICR Mode (B/W)
Zoom 30X Optical Zoom
Focal Length 129 mm to 4.3 mm
Field of View 64° to 2.3° Optical HFOV / 0.2 NFOV e-zoom
Spotlight Specifications
Type LED
Lumens 580
Beam 5° Divergence Angle
Physical Characteristics
Camera Size 32.4 cm (12.75 in) diameter by 46 cm (18.1 in) tall
Camera Weight 12.25 kg (27 lb), depending on the camera model
Joystick Size 9.1 X 14.2 X 8.13 cm (3.6 X 5.6 X 3.2 in)
7.4 cm (3 in) above platform including joystick
Joystick Weight 0.45 kg (1 lb)
Power
Camera Input Power 24 Vdc, 2.5 A typical, 5.5 A max
12 Vdc, 5 A typical, 11 A max
Absolute range 12 Vdc to 32 Vdc
JCU II Input Power
Power over Ethernet (PoE) per IEEE 802.3af
Consumption 50 W Nominal, 132 W maximum
Network Specifications
JCU II
10/100/1000 Mbps
M400 Pan/Tilt Camera 100/1000 Mbps
Ethernet Switch 10/100/1000 Mbps
