M400 Web Browser Interface
432-0012-00-12 Version 110 July 2016 24
The functions of the buttons appearing for the M400 cameras are described below:
Zoom In/Zoom Out
These buttons zoom the active camera (IR or daylight). Plus zooms the camera
in; minus zooms the camera out.
Toggle Video Source
This button changes the source of the Live Video image between the IR camera and the
daylight camera. When the daylight camera is selected, only buttons that have a function
on the daylight camera are shown.
Freeze - Visible only
This button freezes the video on the current frame. Click again to return to live video. The
IR video stream is not affected.
Toggle Polarity - IR only
This button changes the polarity of the assigned colors to the different temperatures in a
scene. In the black and white palette for example, hot objects are displayed as white and
cold objects as black, or vice versa.
Toggle Palette - IR only
This button causes the camera to cycle through six different look up table (LUT) color
palettes. Depending on the subjects viewed, one color palette may be preferable to the
others. The Toggle Polarity button allows access to six more palettes.
Perform IR NUC Calibration - IR only
This button causes the camera to perform a Non-Uniformity Correction operation.
Toggle Scene Preset
This button causes the camera to cycle through four different image settings: Night, Day,
Dock, and High Contrast. The Scene Presets cause the image brightness and contrast to
adjust. Depending on the time of day, weather, and other conditions, one Scene Preset
may be preferable to the others.
Toggle Automatic Gain Control (AGC)
This button causes the camera to cycle through different AGC options that use a
combination of settings to produce different configurations that could improve the video
image for a given set of conditions.
AutoFocus
This button causes the camera to perform a focus function.
Toggle Low Light Mode - Visible only
This button causes the camera to enter or exit low light mode.
