427-0014-00-10 Revision 210 Copyright © 2008 FLIR Systems, Inc. 10
Users can control the camera through a Windows®-based graphical user interface. Users can
also control the SR-100 and SR-100P cameras with devices that support the Pelco® D protocol.
Either method allows the user to operate the following functions or features:
• Camera focus (SR-100 and SR-100P only)
• Digital zoom (2X)
• Selectable Automatic Gain Control (AGC) and Dynamic Detail Enhancement (DDE)
settings for optimization of video imagery
• Camera Palette (also known as Polarity) - by default the White Hot palette is used;
alternatively the Black Hot palette displays warmer objects as black or dark rather than
white or light shades. Additional pseudo color palettes are available using the application
software supplied with the camera.
Figure 2-2: White Hot palette on left, Black Hot palette on right
2.3 Camera Enclosures
SR-Series cameras are packaged in environmental enclosures that meet IPX6 test standards.
Refer to section 9.0 SR-Series Camera Specifications
for additional information. The camera’s
sun shroud around the enclosure helps regulate the camera temperature in direct-sun
installations. Each camera uses an athermalized lens (except for the SR-100P) and a lens or
window heater to provide sharp imagery in all temperature and weather conditions, ensuring a
clear lens and high-quality infrared video, even in extremely cold environments.
Figure 2-3: SR-35 Camera with and without the Environmental Enclosure
