10.0 KBD300 COMMANDS (SR-100, SR-100P)
Note: To start, type the device id (99 is the universal id) and then press CAM
Keystrokes Camera Function Toggle Values (default to first
value)
Near button Increments Focus closer
Far button Increments Focus farther
Note: Holding the Near or Far button
down continuously will only move
the focus for three seconds. The
button must be let go and depressed
for further motion.
CW Joystick Turns on 2X Electronic zoom
CCW Joystick Turns off 2X Electronic zoom
1, Aux On IR Polarity to Black Hot
1, Aux Off IR Polarity to White Hot
2, Aux On Turns on 2X Electronic zoom
2, Aux Off Turns off 2X Electronic zoom
3, Aux On Toggle: Plateau Values 250, 300, 400, 50, 150, 200
3, Aux Off Toggle: AGC Type Plateau, AutoBright, Linear, Plateau,
AutoBright, Linear
4, Aux Off IR Flat Field Correction
5, Aux Off Toggle: LUT Palette White, Black, Sepia, Color1, FireIce,
Rain
6, Aux On Toggle: DDE gain in photon 32, 64, 96, 128, 16, 24
6, Aux Off Toggle: AGC ROI Full, Horizon, Sky, Ground, Center,
Center (smaller)
7, Aux On Toggle: MID ITT in Photon 140, 160, 200, 60, 100, 120
7, Aux Off Toggle: Max gain value 8, 10, 12, 2, 4, 6
Some Pelco keyboards can produce very rapid commands when both of the focus buttons are
pressed simultaneously. These back to back commands can cause the SR camera to continue
to change its focus even when the focus buttons are released. Pressing and releasing either of
the focus buttons again will cause the camera to stop changing its focus and regular focusing
operations can be resumed.
