427-0014-00-10 Revision 210 Copyright © 2008 FLIR Systems, Inc. 3
TABLE OF CONTENTS
1.0 WARNINGS AND CAUTIONS ...................................................................... 6
2.0 INTRODUCTION........................................................................................... 7
2.1 SR-Series Camera Models................................................................................. 7
2.2 Serial Remote Control ........................................................................................ 8
2.3 Camera Enclosures ............................................................................................ 9
2.4 Package Contents ............................................................................................ 10
3.0 INSTALLATION .......................................................................................... 11
3.1 Accessing the Electrical Connections............................................................... 11
3.2 Ground Connection .......................................................................................... 12
3.3 Input Power ...................................................................................................... 13
3.4 Serial Communications..................................................................................... 13
3.5 Sealed Cable Glands........................................................................................ 14
3.6 Analog Video Output ........................................................................................ 15
3.7 Camera Mounting ............................................................................................. 15
4.0 SR-100 INSTALLATION ............................................................................. 16
5.0 SR-100P INSTALLATION........................................................................... 18
6.0 VSR-6, SR-19, SR35, SR-50 INSTALLATION............................................ 21
6.1 Open Camera Enclosure .................................................................................. 21
6.2 DIP Switch Settings .......................................................................................... 22
6.3 Camera Installation........................................................................................... 22
7.0 OPERATING THE SR-SERIES THERMAL CAMERA................................ 25
7.1 Advantages of Thermal Imaging....................................................................... 25
7.2 Thermal Imaging............................................................................................... 25
7.3 Configuration and Control................................................................................. 26
7.4 Pelco Keyboard Control (SR-100 and SR-100P only) ...................................... 27
7.5 Flat Field Correction (FFC)............................................................................... 27
8.0 CARING FOR YOUR SR-SERIES THERMAL CAMERA ........................... 28
8.1 Temperature ..................................................................................................... 28
8.2 Maintenance ..................................................................................................... 28
8.3 Troubleshooting Problems................................................................................ 29
9.0 SR-SERIES CAMERA SPECIFICATIONS.................................................. 31
9.1 SR-Series Camera Dimensions........................................................................ 32
9.2 SR-100P Specifications.................................................................................... 33
9.3 SR-100P Dimensions ....................................................................................... 34
