427-0014-00-10 Revision 210 Copyright © 2008 FLIR Systems, Inc. 32
9.0 SR-SERIES CAMERA SPECIFICATIONS
Feature VSR-6 SR-19 SR-35,
SR-50
SR-100 SR-100P
FPA size (HxV) 160x120 320x240 320x240 320x240 320x240
Weight 4.6 lbs, 2.1
kg
4.6 lbs,
2.1 kg
5.0 lbs,
2.7 kg
7.2 lbs, 3.3
kg
11.5 lbs, 5.2
kg
Dimensions Refer to detailed drawings below in section 9.1
Sensor type Uncooled Microbolometer
Spectral range 7.5 to 13μm
Pixel pitch 38 microns
Input power
range
14V to 32VDC Voltages as measured at the input to the electrical
18V to 27VAC interface board.
Nominal/Peak
Power Req.
6/16 W at 24VDC 4/6 W at
24VDC
8 /36 W at
24VDC
8 /36 W at
24VDC
Fuse 2 Amp fast-blow mini blade fuse,
Ex. Bussman BK/ATM-2 or
equivalent
3 Amp fast-blow mini blade
fuse, 3A/32V
Ex. Littelfuse 2970003 or
equivalent
Operating
Temp. Range
-32°C to 55°C (-25°F to 131°F)
Storage
Temperature
-50° to 85°C
Lens Heater Thermostat controlled
Analog video NTSC or PAL (EIA-170 or CCIR 624, respectively).
Camera focus Fixed focus (no adjustment needed) Motorized focus mechanism
Minimum
Focus
0.1 meters 0.1 meters 1 meter,
4 meters
7 meters 7 meters
Serial remote
interface
RS-232, RS-422
RS-422 (RS-232 available)
User Control Windows-based application program
(known as TVIS User Interface GUI
or Photon GUI)
Via devices supporting Pelco-
D protocol or Windows-based
application program (TVIS-7
User Interface GUI)
Connector
Style
Screw terminals (accepts tinned wire leads) 16-pin mating
connector
Note: These specifications are subject to change without notice. Additional SR-100P
specifications provided in section 9.2 SR-100P Specifications
.
