Technical data26
Data communication interfaces
SD Card One card slot for removable SD memory cards
Audio Microphone headset via Bluetooth for the voice
annotation of images
USB
USB USB Micro-B: data transfer to and from a PC, un-
compressed colorized video
USB, standard
• USB 2.0 High Speed
• USB Micro-B connector
• USB3 Vision via HSI box
Video
Video out
• HDMI 640 × 480
• HDMI 1280 × 720
• DVI 640 × 480
• DVI 800 × 600
Video, connector type HDMI type C
Radio
Wi-Fi
• Standard: 802.11 b/g/n
• Frequency range: 2412–2462 MHz
• Max. output power: 15 dBm
Bluetooth Frequency range: 2402–2480 MHz, supports 2.1
and 4.0
Antenna Internal
Power system
Battery type Rechargeable Li ion battery
Battery operating time >2.5 hours at 25°C (+68°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or
two-bay charger
Charging time
2.5 hours to 90% capacity, charging status indi-
cated by LEDs
Charging temperature 0°C to +45°C (+32°F to +113°F), except for the
Korean market: +10°C to +45°C (+50°F to +113°
F)
External power operation
AC adapter 90–260 V AC, 50/60 Hz or 12 V from a
vehicle (cable with a standard plug, optional)
Power management Automatic power-off functionality, user configura-
ble between 5 minutes, 20 minutes, and no auto-
matic shutdown
Environmental data
Operating temperature range –15°C to +50°C (+5°F to +122°F)
Storage temperature range –40 to +70°C (–40 to +158°F)
Humidity (operating and storage) IEC 60068-2-30 / 24 hours, 95% relative humidity,
25–40°C (77–104°F) / 2 cycles
EMC
• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission)
• ICES-003
Radio spectrum
• ETSI EN 300 328
• FCC Part 15.247
• RSS-247 issue 1
#T559954; r. AP/42311/42335; en-US
178
