Page 40CWT S5 Installation & Maintenance ManualIssue 5
Product description
Connector
Com port
Type
Function
J9
Com 2
CWT Cap Bus
J10
nput (e.g. Seismic alarm)
J11
Not mounted
J12
Relay Output
J13
Com 9
Internal SPI UART
Touch for DMC-EXC7237 (i.e non S5) -
Serial 4
J14
Battery power in
J15
Touch controller AM-EXC3132 (i.e S5)
J16
CWT Cap Bus
J17
Not mounted
J18
Coin Box (1/2)
Lower Door (3/4)
J19
Battery voltage
12V_1 - power output, primarily for extpu
card readers
J20
Upper Door switch
J21
Not mounted
J22
Com 8
External SPI UART
Printer Gebe/Flowbird - Serial 3
J23
Status LEDS and Ambient light sensor
J24
Com 1
External SPI UART
SCA, Smart Coin Acceptor - Serial 5
J25
AVR JTAG (for loading of AVR software)
J26
USB Device (type B)
J27
Solar Panel Input – Min 10V, Max 29 V,
Max 2.5 A
J28
STN Display
J29
Battery voltage
12V_2 - power output
J30
Debug port
J31
Com 4 (**
Internal iMX53 UART
Expansion board
J32
Wake up button
