24
The various menu texts are described below.
Auto-Cal Auto-tuning and calibration of end positions
Start tune Starts the tuning. Questions/commands are displayed during
calibration. Select the type of movement, function, etc. with
and confirm with OK.
Lose prev value? OK? A warning that the value set previously will be lost (not during
the first auto-tuning).
Actuator? rotating Select for rotating actuator.
Actuator? linear Select for linear actuator.
Actuator single act Select for single act.
Actuator double act Select for double act.
Direction? direct Select for direct function.
Direction? reverse Select for reverse function.
In service? Press OK Calibration finished. Press OK to start positioner functioning.
(If ESC is pressed, the positioner assumes the “Out of service”
position but the calibration is retained).
TravelCal Calibration of end positions
Start cal Start end position calibration.
Lose prev value? OK? A warning that the previously set value will be lost.
Confirm with OK.
The calibration sequence starts.
In service? Press OK Calibration finished. Press OK to start positioner functioning.
(If ESC is pressed, the positioner assumes the “Out of service”
position but the calibration is retained).
Perform Setting gain
Normal 100% gain
Perform 50%, 25%,
12%, L, M, S Possibility to select a lower gain in steps.
L, M, S Preset values for L, M, S actuators
Factory set Resets all set values and enters Factory Mode. Should only
be used by authorized staff.
Note. Original P. I. D. will always be shown in display
BASIC MENU
CALIBRATE
