Power Recorder
Features
5
You can also order the following optional accessories. For more information about
accessories, see Contacting Fluke earlier in this manual. An updated list is always
available on www.fluke.com
.
Soft Carry Bag
Hard Transit Case
Security Cable
Replacement Ethernet Cable Kit
Various Current Probes
Replacement Voltage Lead Set
Clamp-on Current Transformers (3005R)
Flexible Current Transformers (3110, 3210, 3310, 3312)
Interface and Extension Cables
3570 CT Cable
Features
The Recorder front panel is illustrated in Figure 1 and described in Table 3.
SD
ETHERNET
POWER
1750
POWER RECORDER
ON
BUSYLINK
100-240 V
47-63Hz
BACN
VO LTAGE
CURRENT
4
13
1
2
3
11
10
8
12
7
5
6
9
azd09f.eps
Figure 1. Fluke 1750 Power Recorder
WCaution
Connecting the supplemental ground terminal and the line cord
safety ground to different ground potentials creates a ground
loop that can damage the Recorder.
