Fluke 196 - Page 110

Fluke 192/196/199
Users Manual
102
0.01
1
2
5
10
20
50
100
200
500
1000
0.02 0.05 0.1 0.2 0.5 1 2 5 10 20 50 100 200
FREQUENCY (MHz)
MAX. INPUT
VOLTAGE (Vrms)
CAT III
CAT II
Figure 53. Max. Voltage From Probe Tip to Ground
and From Probe Tip to Probe Reference
0.01
1
2
5
10
20
50
100
200
500
1000
0.02 0.05 0.1 0.2 0.5 1 2 5 10 20 50 100 200
FREQUENCY (MHz)
MAX. VOLTAGE
FROM PROBE REFERENCE
TO GROUND
CAT III
CAT II
Figure 54. Safe Handling: Max. Voltage From Probe
Reference to Ground
