Fluke 196 - Meter; DMM Measurements on Meter Inputs

Fluke 192/196/199
Users Manual
94
Meter
Meter Input
Input Coupling ..........................................................DC
Frequency Response.....................DC to 10 kHz (-3 dB)
Input Impedance..............1 M
Ω (±1 %)//10 pF (±1.5 pF)
Max. Input Voltage ............................ 1000 V CAT II
600 V CAT III
(For detailed specifications, see “Safety”)
Meter Functions
Ranging.................................................... Auto, Manual
Modes ................................................. Normal, Relative
DMM Measurements on Meter Inputs
The accuracy of all measurements is within ± (% of
reading + number of counts) from 18
°C to 28 °C.
Add 0.1x (specific accuracy) for each
°C below 18 °C or
above 28
°C.
General
DC Common Mode Rejection (CMRR) ................ >100 dB
AC Common Mode Rejection at 50, 60, or 400 Hz ......>60 dB
Ohms ( Ω )
Ranges.............................. 500.0 Ω, 5.000 kΩ, 50.00 kΩ,
500.0 k
Ω, 5.000 MΩ, 30.00 MΩ
Full Scale Reading
500
Ω to 5 MΩ ........................................... 5000 counts
30 M
Ω........................................................ 3000 counts
Accuracy.............................................
±(0.6 % +5 counts)
Measurement Current................. 0.5 mA to 50 nA,
±20 %
decreases with increasing ranges
Open Circuit Voltage.................................................<4 V
Continuity (CONT)
Beep.......................................................<50 Ω (±30 Ω)
Measurement Current............................ 0.5 mA,
±20 %
Detection of shorts of...........................................
≥1 ms
