Fluke 5080A Service Manual

5080A
Service Manual
34
Table 18. Voltage Function Verification: AC Voltage into a 1 MΩ Load (cont.)
Nominal Value (p-p) Frequency
Measured Value
(p-p)
Deviation (mV)
1-Year Spec.
(mV)
20.0 mV 10 kHz 0.15
50.0 mV 10 kHz 0.23
89.0 mV 10 Hz 0.32
89.0 mV 10 kHz 0.32
100.0 mV 10 kHz 0.55
200.0 mV 100 Hz 0.60
200.0 mV 1 kHz 0.60
500.0 mV 10 kHz 1.35
890.0 mV 10 Hz 2.32
890.0 mV 10 kHz 2.32
1.0 V 100 Hz 2.60
1.0 V 1 kHz 2.60
1.0 V 10 kHz 2.60
2.0 V 10 kHz 5.10
5.0 V 10 Hz 12.60
5.0 V 10 kHz 12.60
10.0 V 10 kHz 25.10
20.0 V 10 kHz 50.10
50.0 V 10 Hz 125.10
50.0 V 100 Hz 125.10
50.0 V 1 kHz 125.10
50.0 V 10 kHz 125.10
105.0 V 100 Hz 262.60
105.0 V 1 kHz 262.60
Table 19. Voltage Function Verification: AC Voltage into a 50 Ω Load
Nominal Value (p-p) Frequency
Measured Value
(p-p)
Deviation (mV)
1-Year Spec.
(mV)
5.0 mV 10 Hz 0.11
5.0 mV 100 Hz 0.11
5.0 mV 1 kHz 0.11
5.0 mV 5 kHz 0.11
5.0 mV 10 kHz 0.11
