Fluke 5080A Service Manual

Calibrator
Performance Tests
35
Table 19. Voltage Function Verification: AC Voltage into a 50 Ω Load (cont.)
Nominal Value (p-p) Frequency
Measured Value
(p-p)
Deviation (mV)
1-Year Spec.
(mV)
10.0 mV 100 Hz 0.12
10.0 mV 1 kHz 0.12
10.0 mV 10 kHz 0.12
20.0 mV 10 kHz 0.15
44.9 mV 10 Hz 0.15
44.9 mV 10 kHz 0.21
50.0 mV 10 kHz 0.23
100.0 mV 100 Hz 0.35
100.0 mV 1 kHz 0.35
100.0 mV 10 kHz 0.35
200.0 mV 10 kHz 0.60
449.0 mV 10 Hz 1.22
449.0 mV 10 kHz 1.22
500.0 mV 10 kHz 1.35
1.0 V 100 Hz 2.60
1.0 V 1 kHz 2.60
1.0 V 10 kHz 2.60
2.0 V 10 Hz 5.10
2.0 V 100 Hz 5.10
2.0 V 1 kHz 5.10
2.0 V 5 kHz 5.10
2.0 V 10 kHz 5.10
Table 20. Voltage Function Verification: DC Voltage into a 50 Ω Load
Nominal Value (dc) Measured Value (dc) Deviation (mV) 1-Year Spec. (mV)
0.0 mV 0.10
5.0 mV 0.11
-5.0 mV 0.11
10.0 mV 0.12
-10.0 mV 0.12
22.0 mV 0.15
-22.0 mV 0.15
25.0 mV 0.16
