Table 4. Key Functions (cont.)
No Name Description
L
TRIGGER/STOP
L
Cycles through :
E Slow repeating 0 % - 100 % - 0 % ramp
P Fast repeating 0 % - 100 % - 0 % ramp
N Repeating 0 % - 100 % - 0 % ramp in 25 % steps
Used for the pulse train and totalizer functions.
M
XW Y Z
Return to
Recall
Increases or decreases the source level.
Cycles through the 2-, 3-, and 4-wire selections.
Moves through the memory locations of Calibrator setups.
Moves through the configuration menus.
N
S
ENTER
Saves and recalls setups & data.
ENTER is used in the configuration menus.
O
C
Used to enter and navigate the configuration menus.
P
M
Cycles the Calibrator through MEASURE and SOURCE modes in the lower display.
Q T
Selects TC (thermocouple) measurement and sourcing function in the lower display. Repeated
pushes cycle through the thermocouple types.
R
HART
V
Toggles between voltage, mA sourcing, or mA simulate functions in the lower display.
Inserts a 250 Ω resistor when in mA.
S R
Selects RTD (resistance temperature detector) measurement and sourcing function in lower
display. Repeated pushes cycle through the RTD types. Selects resistance mode.
T U
Selects the pressure measurement and sourcing function. Repeated pushes cycle through the
different pressure units.

Fluke 726 Specifications

General

Auto-ramp function	Yes
Measuring parameters	Current, Frequency, Resistance, Temperature, Voltage
Frequency source accuracy	0.5 %
Frequency measurement accuracy	0.05 %
DC current measurement accuracy	0.01 %
DC voltage measurement accuracy	0.025 %
Resistance measurement accuracy	0.015 %
Product color	Black, Yellow

Weight and Dimensions

Depth	47 mm
Width	96 mm
Height	200 mm
Weight	650 g
