Fluke 8062A - High Frequency Probe (85 RF)

8062A
Instruction Manual
6-8
EXTENDED FREQUENCY
RESPONSE.......................................
Useful for relative readings from 20
kHz to 250 MHz
RESPONSE....................................... Responds to the peak value of an
input and is calibrated to read rms
value of a sine wave.
VOLTAGE RANGE ......................... 0.25 to 30V rms
MAXIMUM INPUT VOLTAGE...... 30V rms, 200V dc
INPUT CAPACITANCE .................. Approximately 3 pF
TEMPERATURE RANGE
Operating.........................................
Storage ............................................
+10
°
C to +35
°
C
-40
°
C to +75
°
C
HUMIDITY ...................................... <90% R.H.
OUTPUT CONNECTOR.................. Fits standard 0.75-inch dual banana
connectors
6-8. High Frequency Probe (85RF)
The Model 85RF High Frequency Probe allows measurements over a
frequency range of 100 kHz to 500 MHz from .25V to 30V rms. It operates
in conjunction with the instruments dc voltage ranges and provides a dc
output that is calibrated to be equivalent to the rms value of a sinewave input.
AC-to-DC RATIO............................. 1:1
RATIO ACCURACY (At 1 MHz
and loaded with 10 M
Ω
)
Above 0.5V .....................................
Below 0.5V .....................................
±
0.5 dB
±
1.0 dB
FREQUENCY RESPONSE
(Relative to 1 MHz)
100 kHz to 100 MHz.......................
*100 MHz to 200 MHz ...................
*200 MHz to 500 MHz ...................
*Referred to high and low inputs at
probe tip.
±
0.5 dB
±
1.0 dB
±3.0 dB
EXTENDED FREQUENCY
RESPONSE.......................................
Useful for relative readings from 20
