6-14. Slim Flex Test Lead Set (Y8140)
The Y8140 Test Lead Set consists of one red and one black 60-inch (1.52
meter) test lead, each with a standard banana plug on one end and an
extendable tip probe on the other end. This flexible metallic tip conductor
may be extended up to 2.5 inches and is insulated to within 0.1 inch of its tip.
This insulation reduces the chance of creating an inadvertent short circuit
while using the probes in their extended configuration. Intended primarily for
measuring voltages, the Y8140 leads may also be used for measuring modest
currents.
6-15. Cables and Adapters
A variety of cables and adapters are available for use with the 8062A, and
are listed in Table 6-1.
Table 6-1. Cables and BNC, Banana, Phone and Phono Plug Adapters
Model Description
Y9105
Y9106
Y9107
Y9108
Y9109
Y9110
Y9111
Y9112
Y9113
Y9114
Y9115
Y9116
Y9117
Y9118
Y9119
Adapter: Insulated alligator clip-banana plug (pkg. of 10)
BNC Tee, jack-jack-jack
BNC Tee, jack-plug-jack
Adapter: BNC-double banana plug
Adapter: Binding post/double banana plug-BNC plug
Adapter: BNC jack-pcb pins
3-foot BNC cable (97 cm), 50Ω RG 58C/U
6-foot BNC cable (1.95 cm), 50Ω RG 58C/U
Adapter: BNC plug-double banana plug
Adapter: BNC jack-.250” phone plug
Adapter: BNC plug-.250” phone jack
Adapter: BNC jack-phono plug
Adapter: BNC plug-phono jack
Adapter: Phone jack-double banana plug
Adapter: Phono jack-double banana plug
