8062A
Instruction Manual
5-6
Table 5-1. 8062A Final Assembly (cont)
Ref.
Des.
Description PN Qty Notes
MP19 PLATE, LCD 612762 1
MP21 INSULATOR, SHIELD 604777 1
MP22 SHIELD, LOWER 587048 1
MP23 SHOCK ABSORBER,LCD 605188 1
MP24 SHOCK ABSORBER 428441 1
MP25 SPACER, CASE 458588 2
MP27 SUPPORT, LCD 612754 1
MP28 SUPPORT, TOP SHIELD 612770 1
MP39 TEST LEAD ASSY, TL70A 855820 1
MP40 BUTTON,FUNC,SW,DK PEWTER, MODIFIED 930347 1
S10 SWITCH, ELASTOMERIC 2 POSITION 604827 1
TM1 8062A INSTRUCTION MANUAL 609153 1
TM2 8062A OPERATOR GUIDE 632703 1
TM3 DMM ACCESSORY GUIDE 825851 1
U3 FINAL TESTED PLASTIC PKG-8060 704759 1 2
U6 LCD, 4.5 DIGIT, MULTIPLEXED 800003 1
W1 GROUND STRIP,BECU,1.980+-.035 817254 1
1. THIS ASSEMBLY IS NON-REPAIRABLE. ENTIRE ASSEMBLY MUST BE REPLACED.
2. THIS COMPONENT IS INSTALLED ON A2 ASSEMBLY.
3. RECOMMENDED SPARE PARTS KIT, PN 646885.
W
TO ENSURE SAFETY, USE EXACT REPLACEMENT ONLY.
