List of Replaceable Parts
5
5-5
Manual Status Information
Ref or
Option No.
Assembly Name
Fluke Part
No.
Revision
Level
A1
A2
A3
Main PCB Assembly
Digital PCB Assembly
RMS PCB Assembly
865808
538306
609120
L
C

Table 5-1. 8062A Final Assembly
Ref.
Des.
Description PN Qty Notes
A1 * MAIN PCB ASSEMBLY 865808 1
A2 * DIGITAL PCB ASSY 538306 1 1
BT1 BATTERY,9V,0-15MA 696534 1
F1 W FUSE,.25X1.0,2A,250V,FAST 376582 2 W
F2 W FUSE,.406,1.375,3A,600V,FAST 475004 1 W
H1 SCREW,PH,P,AM THD FORM,STL,4-14./375 448456 2
H2 SCREW,PH,P,THD FORM,STL,7-19,.750 447953 3
H3 SCREW,FH,P,STL,6-32,.375 837682 1
H4 WASHER,COUNTER SUNK,STAINLESS STEEL 614529 1
MP1 BAIL-STAND, MED PEWTER 616961 1
MP2 BRACKET,LCD MOUNTING 795112 1
MP10 TOP SHIELD 604801 1
MP3 BUTTON,FUNCTION SWITCH-DK PEWTER 606889 3
MP4 BUTTON, POWER SWITCH 456491 1
MP5 BUTTON,RANGE SWITCH-DK UMBER 606871 5
MP6 CASE,BOTTOM, MED PEWTER (CE) 664984 1
MP7 CASE,TOP 8060A MODIFIED (573980) 638635 1
MP8 COVER, BATTERY,MED PEWTER 649126 1
MP9 DECAL, TOP CASE 604785 1
MP11 FLANGE, SWITCH 455881 1
MP12 FOOT, NON-SKID 604397 4
MP13 GASKET, LCD 605170 1
MP14 CONN,ELASTOMERIC,LCD TO PWB,2..153 L 783191 1
MP15 CONN,ELASTOMERIC,LCD TO PWB,2.153 L 587014 1
MP17 LENS 612747 1
