8062A
Instruction Manual
6-10
around conductors up to 3/4 inch in diameter. The pistol shape allows safe,
easy, one-hand operation when making current measurements.
The Model Y8100 probe is battery powered with size AA cells. It measures
current to 200A dc or ac rms using most any voltmeter. Two ranges, 20A and
200A, produce a 2V output at full-range current.
RANGES........................................... 20A ac or dc
200A ac or dc
RATED OUTPUT............................. 2V at full range
ACCURACY
DC to 200 Hz ..................................
200 Hz to 1 kHz ..............................
±
2% of range
<100A add
±
3% reading
>100A add +6% reading
CALIBRATION CYCLE.................. 1 year
FREQUENCY RESPONSE.............. dc to 1.0 kHz
RECOMMENDED LOAD................
≥
3.0 k
Ω
TEMPERATURE RANGE............... +15
°
C to +35
°
C; for specified
accuracy -10
°
C to +50
°
C; storage
and operation at reduced accuracy.
HEATING LIMITATION................. Prolonged operation above 200A ac
or 1 kHz can cause damage to the
Y8100.
WORKING VOLTAGE RATING.... Core to output; 600V dc or 480V ac
maximum output to ground; 42V dc
or 30V ac Max.
APERTURE SIZE............................. 3/4” (19 mm) diameter
SIZE OVERALL............................... 9” x 4-1/2”x 1-7/16” (230 mm x 115
mm x 37 mm)
WEIGHT........................................... 14 ounces (0.4 kg), with batteries
POWER............................................. Battery, four AA cells
BATTERY LIFE............................... Alkaline-20 hours continuous
6-11. AC Current Transformer (Y8101)
The Model Y8101 is a small clamp-on current transformer designed to
extend the current measuring capability of an ac current meter up to 150
amperes. A clamp-on coil designed into the probe allows measurements to
