Fluke BT521 User Manual

Product Overview and Specifications
Standard Equipment 1
1-3
Standard Equipment
The items listed in Table 1-1 are included with the Product.
Table 1-1. Standard Equipment
Item No. Description Quantity Remarks
1 BT521 Meter 1
2 BP500 (battery) 1
7.4 V 3000mAh Lithium-ion
battery
3 BC500 (charger) 1
18 V dc power adapter
4 Power cord 1
5 BTL10 1
6 BTL Adapter 1
7 TL175 1
8 Current clamp i410 1
9 Magnetic plate 1
10 Belt strap 1
11 Shoulder strap 1
12 USB cable 1 Cable length: 1m
13 Safety Sheet 1
14 Large bag 1
15 Zero calibration 1
16 BTL21 1
17 Torch 2
18 Spare fuse 1

Fluke BT521 Specifications

General

Certification	RoHS, IEC 61326
Product color	Black, Yellow
Frequency range	50 - 60 Hz
Maximum measured voltage	600 V
Minimum measured voltage	6 V
International Protection (IP) code	IP40
Operating temperature (T-T)	0 - 40 °C
Display type	LCD
Built-in display	Yes
Battery voltage	7.4 V

Weight and Dimensions

Depth	58 mm
Width	103 mm
Height	220 mm
Weight	850 g
