Fluke BT521 User Manual

BT521
Users Manual
4-2
Table 4-1. Elements of the Handle
Item No. Name Function
 Display
Shows information such as measurement
readings.
 LED
Indicates the status of a measurement. Green
means Pass; orange means Warning; red means
Fail.
 Save button Manually saves a measurement reading.
 Power key Turns on or turns off the handle.
 Backlight key Turns on or turns off the backlight for the handle.
 Speaker Plays audio reminders when enabled.
 Probe tip
Connects the handle to the measured unit. The
probe tips can be replaced.
 Tactile barrier
Hold the handle behind the tactile barrier to
prevent personal injury.
Connect the Probe to the Product
Before the handle and probes are used, connect the probe to the Product. See the
section “Keys and I/O Terminals of the Product”.
Configure the Handle on the Product
Set the Handle Audio
The interactive handle has a speaker that can play audio reminders.
To set the handle audio:
1. Push  to open the Setup screen.
2. Use L to highlight Handle, and push the Select softkey.
Audio is already highlighted.
3. Push the Select softkey.
4. Use  and L to highlight Disable, Threshold result, Battery number, or Both.
5. Push the Confirm softkey.
6. Push the Back softkey to return to the Setup screen.
Set Temperature Unit
To set the temperature unit for the handle:
1. Push  to open the Setup screen.
2. Use L to highlight Handle, and push the Select softkey.
3. Use L to highlight Temperature unit, and push the Select softkey.
4. Use  and L to highlight Celsius or Fahrenheit, and push the Confirm softkey.
5. Push the Back softkey to return to the Setup screen.

Fluke BT521 Specifications

General

Certification	RoHS, IEC 61326
Product color	Black, Yellow
Frequency range	50 - 60 Hz
Maximum measured voltage	600 V
Minimum measured voltage	6 V
International Protection (IP) code	IP40
Operating temperature (T-T)	0 - 40 °C
Display type	LCD
Built-in display	Yes
Battery voltage	7.4 V

Weight and Dimensions

Depth	58 mm
Width	103 mm
Height	220 mm
Weight	850 g
