Fluke BT521 User Manual

Product Overview and Specifications
Accuracy Specifications 1
1-9
Accuracy Specifications
Accuracy is specified for a period of one year after calibration, at 18 °C to 28 °C (64 °F
to 82 °F), with relative humidity to 80 %. Accuracy specifications are given as: ±([% of
reading] + [number of least significant digits]). Accuracy specification assumes ambient
temperature stable ±1 °C.
Function Range Resolution Accuracy
Battery Resistance
[1]
3 mΩ 0.001 mΩ
1 % + 8
30 mΩ 0.01 mΩ
0.8 % + 6
300 mΩ 0.1 mΩ
0.8 % + 6
3000 mΩ 1 mΩ
0.8 % + 6
V dc
6 V 0.001 V
0.09 % +5
60 V 0.01 V
600 V 0.1 V
1000 V 1 V
V ac (45 Hz to 500 Hz with low-
pass filter)
600 V 0.1 V 2 % + 10
Frequency (Display with V ac)
Trigger level: ≥ 10 mV @V ac;
≥ 10 A @A ac
45 Hz to 500 Hz 0.1 Hz 0.5 % + 8
AC Voltage Ripple (20 kHz
max)
600 mV
6000 mV
0.1 mV
1 mV
3 % + 20
3 % + 10
Amps dc/Amps ac (With
accessory Fluke i410)
400 A 1 A 3.5 % + 2
Temperature 0 °C to 60 °C 1 °C ±2 °C
[1] The measurement is based on ac injection method. The injected source signal is <100 mA, 1 kHz.

Fluke BT521 Specifications

General

Certification	RoHS, IEC 61326
Product color	Black, Yellow
Frequency range	50 - 60 Hz
Maximum measured voltage	600 V
Minimum measured voltage	6 V
International Protection (IP) code	IP40
Operating temperature (T-T)	0 - 40 °C
Display type	LCD
Built-in display	Yes
Battery voltage	7.4 V

Weight and Dimensions

Depth	58 mm
Width	103 mm
Height	220 mm
Weight	850 g
