Fluke BT521 User Manual

4-1
Chapter 4
Use the Handle and Probes
Introduction
This Product is shipped with an interactive handle. This chapter provides the information
about how to use the interactive handle and the test probes.
BTL21 Overview
Warning
To prevent possible electrical shock, fire, or personal injury,
hold the handle behind the tactile barrier ().
Figure 4-1 shows the interactive handle. Table 4-2 describes the elements.
3
2
1
5
6
7
1
4
hsz022.eps
Figure 4-1. Interactive Handle

Fluke BT521 Specifications

General

Certification	RoHS, IEC 61326
Product color	Black, Yellow
Frequency range	50 - 60 Hz
Maximum measured voltage	600 V
Minimum measured voltage	6 V
International Protection (IP) code	IP40
Operating temperature (T-T)	0 - 40 °C
Display type	LCD
Built-in display	Yes
Battery voltage	7.4 V

Weight and Dimensions

Depth	58 mm
Width	103 mm
Height	220 mm
Weight	850 g
