viii
CertiFiber Pro Fiber Optical Loss Test Set
Users Manual
19. Result for Smart Remote Mode (Unsaved
Bi-Directional Results Shown) .........................................62
20. Equipment for Autotests in Loopback Mode.................65
21. Connections for Loopback Mode
(1 Jumper Reference, Multimode Fiber).........................67
22. Result for Loopback Mode..............................................70
23. Equipment for Autotests in Far End Source Mode........73
24. Connections for Far End Source Mode
(1 Jumper Reference Multimode Fiber)..........................76
25. Result for Far End Source Mode .....................................79
26. Equipment for the FiberInspector Test ..........................83
27. FiberInspector Image with Measurement Scales
(fiber with 50 µm core shown) .......................................86
28. Equipment for Visual Fault Locator Tests ......................90
29. How to Use the Visual Fault Locator ..............................92
30. Equipment for Power Meter Measurements .................94
31. Connections to Monitor Power and Loss .......................95
32. Power Meter Measurements and Controls ....................96
33. Light Source Controls for the Main Tester .....................99
34. RESULTS Screen ................................................................102
35. How to Connect the Tester to a PC ................................109
36. PROJECT Screen ...............................................................113
37. CABLE ID SETUP Screen
(after you enter the first and last IDs)............................116
38. How to Connect the Tester to a PC ................................125
39. How to Connect Units Together to Update
the Software ....................................................................127
40. How to Remove the Battery ...........................................129
B-1. Modified 1 Jumper Reference Method for
Smart Remote Mode .......................................................136
