iTuner Manual
28
Examples:
MODE LOAD
MODE SOURCE
Set LOAD tuning mode
Set SOURCE tuning mode
4.4.4 Dir Command
Call DIR to display a directory of the calibration data stored in tuner
Syntax:
DIR
Parameter:
None
Return value:
Always 0
Remarks:
A typical DIR reply is shown below:
Nbr ID Freq[GHz] Type Flags Points Xmax Ymax Addr
#001: 0097 1.0000 0 0x00 325 5905 3210 96
#002: 0106 3.5000 0 0x00 466 1687 3210 105
#003: 0119 6.0000 0 0x00 327 984 3210 118
#004: 0128 1.0000 0 0x00 325 5905 3210 127
#005: 0128 2.0000 0 0x00 325 5905 3210 136
#006: 0128 3.0000 0 0x00 325 5905 3210 145
#007: 0155 0.8000 0 0x00 325 7380 7360 154
#008: 0155 0.8000 1 0x00 325 7380 6655 163
#009: 0173 0.8690 3 0x00 441 3440 2280 172
In above example, the first data set (ID=0097) is a single frequency calibration
with 325 points at a primary frequency of 1.0 GHz. Horizontal movement ranges
from 0 to 5905 (Xmax), the vertical axis moves between 0 and 3210 (Ymax).
The second calibration (ID=106) is a single frequency cal at 3.5 GHz, but with
higher resolution (466 points).
Calibration #4 to #6 all have the same ID=128. This is a multi-frequency
calibration, primary frequency is 1.0GHz, with two secondary frequencies,
2.0GHz and 3.0GHz. All 3 calibration sets have the same number of points, Xmax
