iTuner Manual
62
6.1.1 Frequency Definition
Figure 6-3
The Frequency Definition window (as depicted above) is used to define frequency lists to
be used when calibrating a tuner. Close the window once the desired frequency lists are
defined and checked.
To calibrate a list of
frequencies, place a
check in the checkbox.
Select Fo LIST, FREQ
SWEEP or HARMONIC
SWEEP and enter the
required frequency
information and press
Create.
