iTuner Manual
29
and Ymax values. Calling LOADCAL 128 will load all three data sets.
Calibration #7 and #8 also have identical ID=155, and both have the same
frequency f=0.8GHz. However, cal#8 has a different type. Type=1 identifies a data
for the pre-match section of the tuner (PMT only). Calling LOADCAL 0155 will
load both the tuning and the pre-matching calibration data.
Calibration#9 has type=3. These are the calibration data for a harmonic tuner.
Examples:
DIR
4.4.5 Loadcal Command
Call LOADCAL to load calibration data
Syntax:
LOADCAL idx
Parameter:
idx
Index of calibration data, as shown by DIR command
Return value:
0 -> syntax okay
<0 -> no calibration data found
Remarks:
Resets adapter and term
In case the current horizontal position if the carriage is outside the calibration
range of the newly loaded frequency, the carriage will be move to the new Xmax
position.
Use FREQ? to verify frequency definitions
Examples:
LOADCAL 128
Will load calibration data for primary frequency at 1.0GHz,
and secondary frequencies 2.0 & 3.0GHz
(see DIR command above)
4.4.6 Loadfreq Command
Call LOADFREQ to load calibration data for a given primary frequency
Syntax:
LOADFREQ freqMHZ [maxDelta]
Parameter:
freqMHZ
maxDelta
Primary frequency of calibration data
Maximum frequeny deviation from freqMHZ
Return value:
0 -> syntax okay
<0 -> no calibration data found
